Stainless Steel Knitted Wire Mesh, Mainly 0.20mm, 0.23mm, 0.25mm,
0.28mm Wire
Knitted Wire Mesh Introduction:
Knitted wire mesh is made of either crochet or knitting of various
wire materials including stainless steel, copper, synthetic fiber
and other materials.
Knitted wire mesh products are applied to those applications
including cryogenic, high temperature, corrosive atmosphere, heat
conductive, high usage, or special service applications.
Our knitted wire mesh is made from all material available in wire
shapes for processing of the following parts:
Filters Oil and Air Breather Elements Catalytic Converter Mesh
Insulator Blanket Mesh Mufflers and Silencers Copper Mesh Oil-Bath
Separators Mist Elimination Pads Ground Wire Mesh
Specifications:
| Specification of flat wire stainless steel knitted mesh |
| Wire Diameter (mm) | Mesh Opening/ Loop Size (mm) | Number of Needles | Maximum Width (mm) | Minimum Width (mm) |
| 0.1 × 0.3 | 2 × 4 | 36 | 60 | 55 |
| 0.1 × 0.3 | 4.5 × 4 2.5 × 4 | 34 | 150 | 100 |
| 0.1 × 0.4 | 4.5 × 5.5 2.5 × 5.5 | 40 | 150 | 120 |
| 0.1 × 0.4 | 4 × 3.5 2.5 × 3.5 | 56 | 205 | 180 |
| 0.1 × 0.4 | 4 × 4 3 × 4 | 65 | 260 | 240 |
| 0.2 × 0.4 | 5.2 × 3.5 3 × 3.5 | 94 | 420 | 380 |
| 0.2 × 0.4 | 7.5 × 5 5 × 5 | 102 | 565 | 490 |
| 0.2 × 0.5 | 5 × 4 2.5 × 4 | 128 | 560 | 470 |
| Specification of round wire stainless steel knitted mesh |
| Wire Diameter (mm) | Width (mm) | Number of Stitches Per cm on Length | Number of Stitches Per cm Across Lay Flat |
| 0.08 – 0.18 | 6 - 300 | 3.5 | 4.4 |
| 0.16 | 40 - 600 | 2.4 | 3.5 |
| 0.18 - 0.35 | 30 - 1000 | 1.6 | 1.9 |
| 0.25 - 0.40 | 30 - 1000 | 1.6 | 0.74 |
| 0.4 - 0.5 | 100 - 350 | 0.5 | 0.5 |
Other Specifications according to your requests.
Main Materials Applied for Knitted Mesh:
Monel knitted wire mesh has good corrosion resistance in all
extreme environments and it is reasonably conductive and is tough
with high tensile strength, giving good wear characteristics.
Applications:
Knitted wire mesh made of tinned copper clad steel has the best
shielding performance of all wires used in knitted meshes,
combining low contact resistance with a small degree of
permeability. It is not suitable for highly abrasive applications
where the TIN plating may wear away to expose the copper. The
corrosion resistance of tinned copper clad steel knitted wire mesh
is suitable for most applications
Stainless steel knitted mesh is often used as a protective final layer over the other knitted
mesh gasket, materials on order to provide a wear-resistant contact
surface.
Advantages and benefit of stainless steel knitted mesh:
Corrosion resistance.
Alkali and acid resistance.
Rust resistance.
High temperature resistance.
Excellent shielding performance.
Outstanding filtering efficiency.
Durable and long service life.
Packing:
